IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
General guidelines
What is described in this manual?
This manual describes IG/IS-NT-Combi application which covers the SPtM, SPI and MINT applications. The
SPtM, SPI and MINT applications can be switched by the binary inputs (see more at Switching the SPtM,
SPI and MINT applications chapter). The IG/IS-NT-Combi has been designed especially for rental gensets.
Selection among setpoints as Nominal voltage, Nominal RPM, Nominal frequency and enabling or disabling
of synchronization can be done by setpoint or by using of force value that can be changed by corresponding
binary inputs (see more at Force value chapter).
The IG/IS-NT-Combi application also enables increasing and decreasing of baseload value SPtM or SPI
application Binary inputs ( BaseLoad Up and BaseLoad Down) or manual fuse synchronizing function
(MCB).
What is the purpose of this manual?
This manual provides general information on how to configure and operate the controller.
This manual is intended for use by:
Operators of gen-sets
Gen-set control panel builders
For everybody who is concerned with installation, operation and maintenance of the gen-set
!! Warnings !!
The NT controller can be remotely controlled. In the event that maintenance needs to be done to the gen-set,
check the following to ensure that the engine cannot be started.
To be sure:
Disconnect remote control via RS232 line
Disconnect input REMOTE START/STOP
or
Disconnect output STARTER and outputs GCB CLOSE/OPEN and MCB CLOSE/OPEN
The controller contains a large number of configurable setpoints, because of this it is impossible to describe
all of its functions. These are subject to change from SW version to SW version. This manual only describes
the product and is not guaranteed to be set for your application on arrival.
Text
ESC (Capital letters in the frame) buttons on the front panel
Break Return (Italic) set points
Generator protections (Bold) Set point group
Cyan background Valid for IS-NT only
Conformity declaration
Following described machine complies with the appropriate basic safety and health
requirement of the EC Low Voltage Directive No: 73/23 / EEC and EC
Electromagnetic Compatibility Directive 89/336 / EEC based on its design and type,
as brought into circulation by us.
Note:
ComAp believes that all information provided herein is correct and reliable and reserves the right to update
at any time. ComAp does not assume any responsibility for its use unless otherwise expressly undertaken.
