Table of values
Group: Engine values
Value: RPM
Group
Engine values
Units
1/min
Related FW
3.0
Description
Current engine speed. See the chapter Engine speed measurement for details
about speed measurement methods.
Value: T Cyl aver
Group
Engine values
Units
°C
Related FW
3.0
Description
The value contains average cylinder temperature, i.e. average of all configured
logical analog inputs Cyl temp 1 ... Cyl temp 32
NOTE:
Available in IS-NT only.
Value: T Cyl max
Group
Engine values
Units
°C
Related FW
3.0
Description
The value contains the maximum of all cylinder temperatures, i.e. maximum of all
configured logical analog inputs Cyl temp 1 ... Cyl temp 32
NOTE:
The value is intended for creating the "high cylinder temperature" alarm using an
universal analog protection. There is a special wizard at the I/O tab in GenConfig
which makes the configuration of cylinder temperatures easy.
NOTE:
Available in IS-NT only.
Value: T Cyl min
Group
Engine values
Units
°C
Related FW
3.0
Description
The value contains the minimus of all cylinder temperatures, i.e. maximum of all
configured logical analog inputs Cyl temp 1 ... Cyl temp 32
NOTE:
The value is intended for creating the "misfiring cylinder" alarm using an universal
