IGS-NT-BC, SW Version 1.2.0, ©ComAp January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
159
Related FW
3.0
Description
The angle between the phasors of the bank and mains/bus voltage.
Group: Bus values
Value: Bus freq
Group
Bus values
Units
Hz
Related FW
3.0
Description
Bus frequency. The frequency is measured in the phase L3.
Value: Bus V L1-N
Group
Mains values
Units
V
Related FW
3.0
Description
Bus voltage in phase L1.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint Vm VT ratio.
Value: Bus V L2-N
Group
Bus values
Units
V
Related FW
3.0
Description
Bus voltage in phase L2.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint Vb VT ratio.
Value: Bus V L3-N
Group
Bus values
Units
V
Related FW
3.0
Description
Bus voltage in phase L3.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint Vb VT ratio.
Value: Bus V
Group
Bus values
Units
V
Related FW
3.0
