Description
Bus voltage. Average from all three phases.
NOTE:
The ratio between the voltage measured at the input terminals and the displayed
voltage is adjusted by the setpoint Vb VT ratio.
Value: Bus V L1-L2
Group
Bus values
Units
V
Related FW
3.0
Description
Bus voltage phase L1 to L2.
Value: Bus V L2-L3
Group
Bus values
Units
V
Related FW
3.0
Description
Bus voltage phase L2 to L3.
Value: Bus V L3-L1
Group
Bus values
Units
V
Related FW
3.0
Description
Bus voltage phase L3 to L1.
Value: Bus V unbal
Group
Bus values
Units
V
Related FW
3.0
Description
Bus voltage unbalance. The value is calculated as maximal difference of two
phase voltages at one moment and expressed in % of the Bus nominal voltage.
Value: EarthFC
Group
Bus values
Units
A
Related FW
3.0
Description
This value contains the current measured at the current input labeled "IN". This
input is used for measurement of the earth fault current.
NOTE:
The ratio between the current measured at the input terminals and the displayed
current is adjusted by the setpoints EarthFltCurCTp and Im3/ErFlCurCTs.
