IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
Binary output: Common BOC
The output is closed while there is at least one alarm of the Breaker open&Cool-
down type present in the alarm list. The alarm can be in any state, i.e. active
unconfirmed, active confirmed or inactive unconfirmed. See the chapter Alarm
management for more information.
The output is closed while there is at least one alarm of the Alarm only type
present in the alarm list. The alarm can be in any state, i.e. active unconfirmed,
active confirmed or inactive unconfirmed. See the chapter Alarm management for
more information.
Binary output: Common Hst
The output is closed for 1s when any alarm of History record type appears. See
the chapter Alarm management for more information.
Binary output: CommonActLev 1
The output is closed while there is at least one 1st level (yellow) alarm present in
the alarm list. The alarm can be in any state, i.e. active unconfirmed, active
confirmed or inactive unconfirmed. See the chapter Alarm management for more
information.
Binary output: CommonActLev 2
The output is closed while there is at least one 2nd level (red) alarm present in the
alarm list. The alarm can be in any state, i.e. active unconfirmed, active confirmed
or inactive unconfirmed.See the chapter Alarm management for more information.
Binary output: Alarm flashing
This is the flashing alternative of the output Alarm, i.e. the output flashes with
period 1s/1s while the output Alarm is closed.
