ComAp IG-NTC GC - Page 242

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
242
Binary output: Bin selector 4
Related FW
3.0
Description
Output is closed or opened according to the setpoint Bin selector 4.
NOTE:
The output is intended for ECU-controlled engines to switch on/off some particular
ECU function by a controller setpoint if the function can be controlled by a binary
value over the J1939 bus.
Binary output: WrongPhSeq
Related FW
3.0
Description
Binary output WrongPhSeq is active when at least one of the following conditions
is fulfilled: Generator/Mains/Bus phase is inverted or wrong generator/mains/bus
phase sequence or opposed generator/mains/bus phase sequence is detected.
Binary output: User Button 1
Related FW
3.0
Description
This output can be specified for example on buttons on IV-5/8 or in SCADA
diagram in InteliMonitor. Its state depends on function assigned to the related
button.
It is possible to lock UserButton commands in configuration to specific user level.
Buttons 1-8 and 9-16 are locked separately.
ON
Pressing the button changes the state of log. binary output User
Button X to closed. When the output is closed and the button is
pressed state is not changed.
OFF
Pressing the button changes the state of log. binary output User
Button X to opened. When the output is opened and the button
is pressed state is not changed.
ON/OFF
Pressing the button changes the state of log. binary output User
Button X to opened or closed depending on previous state (it is
changed to the opposite state).
PULSE ON
Pressing the button issues log. binary output User Button X to
close for one second.
NOTE:
Repeated pressing of button during the closed period (one
second) causes issuing another puls of length of one second to
be generated from the moment of button pushing.
Binary output: User Button 2
Related FW
3.0
Description
This output can be specified for example on buttons on IV-5/8 or in SCADA
