IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
The setpoint is used to switch on and off the output Bin selector 4.
OFF, 1s - 3600s, NO TIMEOUT [-]
This setpoint adjusts time after which the Horn output is automatically deactivated
although the alarms still haven't been reset. If the setpoint is adjusted to OFF the
horn output is not activated at all, the NO TIMEOUT position means the horn
output is not deactivated until the alarms are reset.
This setpoint adjusts the delay #1 which can be assigned to an input configured
as alarm input (protection).
NOTE:
Protections configured at a binary inputs can have either fixed 0.5s evaluation
delay or there are three independent delay setpoints and one of them can be
assigned to each particular binary input protection.
This setpoint adjusts the delay #2 which can be assigned to an input configured
as alarm input (protection).
