Page #97 background image
IGS-NT-BC, SW Version 1.2.0, ©ComAp January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
97
NOTE:
Protections configured at a binary inputs can have either fixed 0.5s evaluation
delay or there are three independent delay setpoints and one of them can be
assigned to each particular binary input protection.
Setpoint: BinInp delay 3
Group
Engine protect
Range [units]
0.0 .. 600.0 [s]
Related FW
3.0
Force value
possible
YES
Description
This setpoint adjusts the delay #3 which can be assigned to an input configured
as alarm input (protection).
NOTE:
Protections configured at a binary inputs can have either fixed 0.5s evaluation
delay or there are three independent delay setpoints and one of them can be
assigned to each particular binary input protection.
Setpoint: ForceBlockDel1
Group
Engine protect
Range [units]
0.0 .. 60.0 [s]
Related FW
3.0
Description
This setpoint adjusts the delay after the binary input Force block 1 has been
deactivated, when the alarms configured as Force block #1 are started to be
evaluated.
Setpoint: ForceBlockDel2
Group
Engine protect
Range [units]
0.0 .. 60.0 [s]
Related FW
3.0
Description
This setpoint adjusts the delay after the binary input Force block 2 has been
deactivated, when the alarms configured as Force block #2 are started to be
evaluated.
Setpoint: ForceBlockDel3
Group
Engine protect
Range [units]
0.0 .. 60.0 [s]
Related FW
3.0
