ComAp IG-NTC GC User Manual

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
67
control mode in parallel-to-mains operation is switched to BasePF (i.e. #SysPFCtrl
PtM = BASEPF).
INTERNAL
The required power factor is adjusted by the setpoint
#SysPwrFactor.
EXTERNAL
The baseload is adjusted by the logical (functional) analog
input MPF:AnExSysBPF.
NOTE:
If the external source is selected the logical analog input must be configured at
each gen-set to the identical source. See the note at the setpoint
SysBaseLdMode.
Setpoint: Derating1 strt
Group
Process control
Range [units]
-32000 .. +32000 [x]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used for adjusting the starting point of the Power derating 1
function, where the gen-set nominal power is still 100% of the setpoint Nomin
power.
See the chapter Power derating for details.
NOTE:
The setpoint actual physical dimension depends on configuration of the physical
analog input to which the logical input PowerDerating1 is assigned.
Setpoint: Derating1 end
Group
Process control
Range [units]
-32000 .. +32000 [x]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used for adjusting the end point of the Power derating 1 function,
where the gen-set nominal power is reduced to the value adjusted by setpoint
Derated1 pwr.
See the chapter Power derating for details.
NOTE:
The setpoint actual physical dimension depends on configuration of the physical
analog input to which the logical input PowerDerating1 is assigned.
