NOTE:
You need one of communication modules to connect the controller to a PC with LiteEdit. There is a
special easy removable service module for cases, where there is no communication module
permanently attached.
Once the configuration is modified, it can be stored in a file for later usage with another controller or
for backup purposes. The file is called archive and has file extension "aic". An archive contains full
image of the controller at the moment of saving (if the controller is online to the PC) except firmware,
i.e. besides configuration there are also current adjustment of all setpoints, all measured values, copy
of history log and copy of alarm list.
The archive can be simply used for cloning of InteliPro units, which means preparing units with
identical configuration and settings.
CONFIGURATION WINDOW IN LITEEDIT
CAUTION!
The firmware of this version is compatible only with the archive version 1.4. It is not possible to use for
instance the archive version 1.3.
System of optional functions
The unit offers wide range of protective functionalities. To allow flexibility of the protective functions at
the particular application, some of the features are provided as SW options. These functions are
unlocked by a software dongle, delivered by ComAp or its approved distributors. The SW dongle is a
unique number generated according to the serial number of the unit and the selected protective
functions. The functions are referred by their ANSI numbers, according to the following table:
