List of EMC tests
Test description
Compliant to
Test conditions/ level
Electrical disturbance test
(1MHz burst immunity)
IEC 60255-22-1
IEC 61000-4-18
IEEE C37.90.1
f = 1MHz
U=±0,25,±0,5,±1kV
Electrostatic discharge tests
IEC 60255-22-2
IEC 61000-4-2
Test voltage:
U=±2,±4,±6kVcontactdischarge
U=±2,±4,±8kVairdischarge
Radiated electromagnetic
field immunity test
IEC 60255-22-3
IEC 61000-4-3
IEEE C37.90.2
Field intensity: 10V/m
Scan spectrum:
80 – 1000MHz, 1,4 – 2,7GHz
(80% AM 1kHz)
Electrical fast transient/burst
immunity test
IEC 60255-22-4
IEC 61000-4-4
IEEE C37.90.1
f = 5kHz
U=±2kV
Surge immunity tests
IEC 60255-22-5
IEC 61000-4-5
U=±0,5,±1kV
Immunity to conducted
disturbances induced by
radio –frequency fields
IEC 60255-22-6
IEC 61000-4-6
IEEE C37.90.2
Test voltage: U= 10V
Scan spectrum: 0,15 – 80MHz
(mod.80% AM / 1kHz)
Spot frequencies: 27MHz, 68MHz
Power frequency magnetic
field immunity tests
IEC 60255-22-8
IEC 61000-4-8
Magnetic field intensity:
30/300 A/m
Voltage dips, short
interruptions and voltage
variations on dc input power
port
IEC 60255-11
IEC 61000-4-29
Test level: 0% Ut
Duration [ms]: 5, 10, 20, 50, 100, 200
Electromagnetic emission
tests
CISPR 22
IEC 60255-25
Class A
f = 30 – 1000 MHz
f = 0,15 – 30 MHz
Vibration tests (sinusoidal)
IEC 60255-21-1
IEC 60068-2-6
2÷25Hz/±1,6mm/1octaveper
minute
25÷100Hz/4,0g/1octaveperminute
Shock and bump tests
IEC 60255-21-2
EN 60068-2-27
A=200m/s2; T=11ms; half sinus;
3 shocks in all axis both directions (18
altogether)
Environmental testing
IEC 60068-2-1
Cold: -30°C
Environmental testing
IEC 60068-2-2
Dryheat:+70°C
Environmental testing
IEC 60068-2-3
IEC 60068-2-30
Cyclic damp heat + humidity
Temperature cycle: 20-55-20°C
Humidity: 97%
Isolation rated voltage
IEC 60255-5
Overvoltage category III
