ComAp InteliPro User Manual

InteliPro, SW version 1.4, ©ComAp – April 2014
InteliPro 1.4 Comprehensive Guide - rev. 1
4-44
Extension I/O
IOM AI1
U4
Analog from IOM or PTM module connected via CAN
IOM AI2
U5
Analog from IOM or PTM module connected via CAN
IOM AI3
U6
Analog from IOM or PTM module connected via CAN
IOM AI4
U7
Analog from IOM or PTM module connected via CAN
AIO AI1
U8
Analog input from AIO
AIO AI2
U9
Analog input from AIO
AIO AI3
U10
Analog input from AIO
AIO AI4
U11
Analog input from AIO
IOM Bin Inp
-
8bits binary value from binary inputs of IOM or PTM module
connected via CAN
Relay Card CT2
-
Relay output
RA Bin Out
-
15bits binary value send to RA15 module connected via CAN
IOM Bin Out
-
8bits binary value send to binary outputs of IOM or PTM module
connected via CAN
SharedBOut
-
8bits binary value contains binaries send to shared periphery
SharedAout 1
-
Analog value sends to shared periphery
SharedAout 2
-
Analog value sends to shared periphery
SharedAout 3
-
Analog value sends to shared periphery
SharedAout 4
-
Analog value sends to shared periphery
Statistics
kWh I
kWh
active power import
kVArh I
kVArh
reactive power import
kWh E
kWh
active power export
kVArh E
kVArh
reactive power expoer
Date/Time
Time
-
Time
Date
-
Date
InteliPro Info
Breaker State
FW Version
FW Branch
IOM SW Ver.
PasswordDecode
CAN16
CAN32
Options
