ComAp InteliPro User Manual

InteliPro, SW version 1.4, ©ComAp – April 2014
InteliPro 1.4 Comprehensive Guide - rev. 1
4-43
MPfL3
-
power factror of phase 3
Mains Ld Char
-
Mains load character
M Ld Char 1
-
load character of phase 1
M Ld Char 2
-
load character of phase 2
M Ld Char 3
-
load character of phase 3
LOM
MaxVectorShift
°
Maximal value of vector shift
Act ROCOF
Hz/s
actual value of Rate of Change of Frequency
Max ROCOF
Hz/s
Maximal vlaue of Rate of Change of Frequency
NVD
NVD
V
neutral voltage displacement
Sync Check
Vsc Freq
Hz
Measured frequency of Vsc voltage
Vsc
V
Voltage between L2 and L3 on mains terminals
Slip Freq
Hz
Measured frequency slip between frequency of main three phase
voltage and voltage on L2-L3 of the mains terminals
Angle
°
Shift angle between generator and mains voltage in phase 1
Pole Slip
RPM
RPM
Value of RPM evaluated from magnetic pickup
LoadAngle
°
Load angle
Controller I/O
Aux Volts
V
Auxiliary power voltage
CU AI1
-
Analog input 1 of controller
CU AI2
-
Analog input 2 of controller
CU AI3
-
Analog input 3 of controller
Bin Inputs
-
Binary value with reading from binary input terminals on controller
Bin Outputs
-
Binary value set on binary output terminals on controller
GSM SignalLvl
%
GSM signal strength
GSM ErrorRate
-
Error rate of the GSM signal
GSM Diag Code
-
GSM diagnosis
AirGate Diag
-
AirGate diagnosis
AirGate ID
-
Unique number for AirGate communication
Modem Status
-
Modem status
RemoteControl
-
Remote control
