IGS> T Curve
Selection of which curve will be used for ANSI 51GS: ground surge overcurrent.
IDMT: parametric curve, given by the IGS> T Del and IGS> T Lim parameters as described
in the chapter ground surge time-overcurrent protection.
Mod Inv: moderately inverse curve according to ANSI standard
Very Inv: very inverse curve according to ANSI standard
Ext Inv: extremely inverse curve according to ANSI standard
IECInv: moderately inverse curve according to IEC standard
IECVerInv: very inverse curve according to IEC standard
IECExtInv: extremely inverse curve according to ANSI standard
Default setting: IDMT
IGS Trp BO [Trp 1 / Trp 2 / Trp 1+2 / None]
Selection of trip binary output for ground surge overcurrent protection.
Default setting: None
NVD
NVD> [V]
Threshold for neutral voltage displacement evaluation.
Step: 1 V
Range: 0 - 150 V
0 = OFF, the ANSI 59N - neutral voltage displacement protection is disabled
Default setting: 33 V
NVD> Del [s]
Delay for neutral voltage displacement protection.
Step: 1 s
Range: 0 - 300 s
Default setting: 60 s
NVD>> [V]
Step: 1 V
Range: 0 – 500 V
Default setting: 50 V
NVD>> Del [s]
Step: 1 s
Range: 0 – 300 s
Default setting: 1 s
Rst NVD
Threshold for NVD measurement hysteresis.
Options: +/- 0%
+/- 4%
Default:: +/- 0%
NVD Trp BO [Trp 1 / Trp 2 / Trp 1+2 / None]
Selection of trip binary output for neutral voltage displacement protection.
Default setting: None
