TEST mode (SPtM only)
Use TEST mode for Gen-set start test if the Mains is OK or to transfer the load to the gen-set when
Mains fail is announced in advance.
Hint:
The controller does not respond to GCB ON/OFF , STOP, START in Ret from test = AUTO.
Engine automatically starts, when TEST mode is selected.
Engine can start automatically without warning when pressing FAULT RESET after shut down alarm.
Baseload
Process control: Load ctrl PtM = BASELOAD
Gen-set power is kept at value given by Process control:Base load setpoint.
Internal Import export
ProcessControl: Load ctrl PtM = IMP/EXP
Process control: IE measurement = IM3 CT INPUT
Gen-set power is controlled to keep the import load at the level given by setpoint Process control:
Import load value.
Controller measures Import/Export value via current transformers connected to In/Im3 terminal. The
value of L3 is then multiplied by 3 to give an estimation of the actual Imp/Exp.
