InteliSys
NT
-AFR-Abstract, SW version 1.0, ©ComAp – December 2006 27
IS-NT-AFR-1.0-Abstract.pdf
MAP actual [ 0,000 to 10,000 bar]
actual MAP based on MAP analog input.
O2 actual [ 0,0 to 100,0%]
Actual O2 value based on UEGO analog input.
Statistics values
Following statistics value is additional against to standard InteliSys NT software.
kW hours
Day kWhours
• Visible on Generator [1-5] screen or in WinEdit - Value screen
• It is automatically set to zero each midnight (24:00:00) when controller is switched on
kVArhours
Run hours
Num starts
NumUnscStarts
Service time 1
Service time 2
Service time 3
Service time 4
Hint:
Once a service time has elapsed the corresponding Service time X setpoint must be adjusted again to
a konzero value to clear the alarm and begin a new countdown. You can rename the particular timers
using Translator to indicate specific service intervals – e.g. “OilChange time”, “SparkPlug time”, ...
PulseCounter 1
PulseCounter 2
PulseCounter 3
PulseCounter 4
The inputs are linked with corresponding counters, which integrate the pulses sensed at these inputs.
Each rising edge of the signal at input increases the internal counter value.
Hint:
Pulse width (both high/low levels) must be at least 100 ms in order to be correctly sensed!
Conversion ratio can be selected using the setpoints ConvCoefPulseX. The converted values are
visible in statistics – values PulseCounter X. These values can be reset using Statistics window in
InteliMonitor.
