InteliSys
NT
-AFR-Abstract, SW version 1.0, ©ComAp – December 2006 39
IS-NT-AFR-1.0-Abstract.pdf
Abbreviation list
AMF Auto Mains Failure (controller starts automatically on mains failure)
AI Analog Input
AO Analog Output
ATS
utomatic Transfer Switch (switches the load to actually supplied bus (by mains or generators))
AVR Automatic Voltage Regulator
BI Binary Input
BO Binary Output
BOC Breaker Open & Cool-down - protection type (see application manual for details)
BTB Bus-Tie Breaker
CAN1 CAN bus for extension modules connection (e.g. IGS-PTM, IS-BIN8/16, IS-AIN8, I-AOUT8, I-
CB, IGL-RA15)
CAN2 CAN bus for intercontroller communication (in multiple applications) and monitoring (connection
of I-LB, IG-IB)
COX Application for Complex Systems where actions are taken by a PLC and the controller only
follows the orders => needs an external driver (cox)
ESF Engine Specific File
FMI Failure Mode Identifier
GC
Graphical Characters - option for additional support of one "graphical" language
GCB Generator Circuit Breaker
CHP Combined Heat & Power - cogeneration application, usually with gas engine
I-AOUT8 Extension module with 8 AO
I-CB Communication Bridge - interfaces IS, IG/IS-NT, ID controllers and non-standard engine ECU
IG-AVRi IG Automatic Voltage Regulator interface
IG-EE InteliGen for Electronic Engines (HW optimized for connection to an engine equipped with
ECU)
IG-EEC InteliGen EE controller with extended communication possibilities + switchable sensing ranges
of AC voltages and currents
IG-IB IG Internet Bridge - for internet/ethernet communication
IGL-RA15 Indication panel with LEDs signalizing state of 15 BO
IG-NT InteliGen New Technology gen-set controller
IG-NTC InteliGen NT controller with extended communication possibilities + switchable sensing ranges
of AC voltages and currents
IGS-NT-
LSM+PMS Dongle for IG-XX and IS-NT to enable Load Sharing control loops and PMS
IGS-PTM Extension module with 8 BI/BO, 4 AI and 1 AO
I-LB Local Bridge – for direct and modem monitoring and control of multiple gen-sets
IM-NT InteliMains New Technology - Mains supervision controller; the same controller in a different
SW configuration can work as a bus-tie synchronizer
I-RB Relay Board
IS-AIN8 Extension module with 8 AI.
IS-BIN8/16 Extension module with 8 BO and 16 BI.
IS-NT InteliSys New technology gen-set controller
IS-NT-BB
InteliSys New Technology Basic Box (without display)
KWP2000 Key Word Protocol of Scania S6 unit (for engine diagnostics)
LS Load Sharing - analog load sharing line to interconnect the gen-sets on the site (for isolated
parallel or mains parallel of multiple gen-sets); IG/IS-NT controllers use digital Load Sharing via
