IS–NT Air Fuel Ratio control software
IS-NT-AFR-1.0 is based on standard InteliSys-NT software of version 2.0 and the last standard IS-
AFR-1.5 version. IS-AFR software is compatible with InteliMonitor-2.0 and GenConfig-2.0 PC tools.
Corresponding IS-AFR dongle activates IS-AFR function. Following document describes differences
against standard IS-NT functions only. For standard InteliSys functions description see corresponding
(SPTM, SPI, MINT) user guides.
IS-NT-AFR-1.0.igc pack
Use GenConfig –Option-Import firmware command to import igc pack to GenConfig.
File Note
IS-NT-AFR-1.0.mhx
IS-display-1.1.mhd
IS-Display-1.1.ntd
IS-font-china-1.0.ifo
IS-NT-AFR-1.0.NTF
Application processor
Display processor
Display processor
China font file
Info file
IS-AFR-COX-1.0.ant
IS-AFR-MINT-1.0.ant
IS-AFR-SPI-1.0.ant
IS-AFR-SPTM-1.0.ant
IS-AFR-SPTM-StarterKit-2.0.ant
Default archives
VDO Level CU.CRV
VDO Press CU Bar.CRV
VDO Press CU Psi.CRV
VDO Temp CU °C.CRV
VDO Temp CU °F.CRV
Default sensors
ENG_CHN.trn
Eng_esp.trn
China Dictionary
Spain dictionary
10_134_1_5.IDX Index file
Available documentation
PDF files Description
IS-NT-AFR-1.0 Abstract.pdf
AFR functions description
GenConfig-2.0.pdf Manual for PC configuration tool
InteliMonitor-2.0.pdf Manual for PC monitoring tool
Related documents
IGS-NT-MINT-2.0.pdf
Manual for standard IG/IS-NT Multiple INTernal application
IGS-NT-2.0-Application guide.pdf Application guide for IG/IS-NT
IGS-NT-2.0-Installation guide.pdf Installation guide for IG/IS-NT
IGS-NT-2.0-Operator guide.pdf Operator guide for IG/IS-NT
InteliCommunicationGuide–
September06.pdf
Communication guide for IG/IS-NT, ID and Il controllers
Main changes against the standard IS-AFR-1.5
1. New setpoint limit Engine protect: StartOverspeed [ % ] .
2. New setpoint Engine protect:
StartBlockDel [ s ] .
3. New setpoint Engine protect:
ServiceTime Sd [ h ].
4. New Logical binary output kWh pulses and corresponding setpoint AFR control:
kWh pulse [
kWh ].
5. Removed message “Wrn SpeedRegLimit” in alarm list and in History record.
6. Removed Stop fail indication.
7. New Logical analog input: LdCtrl:AnExBld for Local Baseload from analog input setting (as part
of standard IS-NT system).
8. New programmable logic functions PLC set (as part of standard IS-NT system).
