ComAp IS-NTC-BB Reference Guide

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
109
output OfL StartBlck).
NOTE:
See table with examples in the description of the setpoint MFStart enable.
Setpoint: Synchro enable
Group
Process Control
Range [units]
NONE, FORWARD, REVERSE, BOTH [-]
Related FW
3.0
Force value
possible
YES
Description
The setpoint is used for enable/disable forward and reverse synchronization.
 NONE: No synchronizing is enabled.
 FORWARD: GCB synchronizing is enabled.
 REVERSE: MCB synchronizing is enabled.
 BOTH: GCB and MCB synchronizing are enabled.
NOTE:
Although synchronizing of the particular breaker is disabled the breaker can be
closed to a "dead" (voltage-free) bus.
NOTE:
See table with examples in the description of the setpoint MFStart enable.
Setpoint: MFStart enable
Group
Process Control
Range [units]
NO, YES [-]
Related FW
3.0
Force value
possible
YES
Description
The setpoint is used to enable/disable automatic start of the gen-set when a
mains failure occurs.
EXAMPLES OF SETTINGS:
DESCRIPTION OF THE BEHAVIOR
REQUIRED ADJUSTMENT
AMF gen-set, no synchronizing, no test-on-load
function. This behavior is used if the both MCB and
GCB too slow for synchronizing or if synchronizing
is generally not allowed by the local electricity
company.
Island enable = YES
ParallelEnable = NO
Synchro
enable = NONE
MFStart enable = YES
AMF gen-set with test-on-load function and with
Island enable = YES
