IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
This setpoint adjusts the gain factor (P-factor) of the cos-phi control PI loop. The
integration factor (I-factor) for the cos-phi control loop is adjusted by the setpoint
PF int.
NOTE:
See the chapter Regulation loops overview for general information about
regulation loops and their adjustment.
Setpoint: PF int
This setpoint adjusts the relative integration factor (I-factor) of the cos-phi control
PI loop. The gain factor (P-factor) for the cos-phi control loop is adjusted by the
setpoint PF gain.
Setpoint: AVR DCout bias
This setpoint adjusts the initial level for the AVRi output. This level is present on
the output if no regulation loop is active.
NOTE:
The resulting voltage at the input of the AVR also depends on position of the
trimmer at the AVRi module.
Setpoint: VS gain
This setpoint adjusts the gain factor (P-factor) of the VAr-sharing PI loop. The
integration factor (I-factor) for the VAr-sharing loop is adjusted by the setpoint VS
int.
NOTE:
See the chapter Regulation loops overview for general information about
regulation loops and their adjustment.
Setpoint: VS int
