IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
This setpoint adjusts the relative integration factor (I-factor) of the VAr-sharing PI
loop. The gain factor (P-factor) for the VAr-sharing loop is adjusted by the setpoint
VS gain.
Setpoint: TauVoltActuat
This setpoint is used to adjust the trasformation ratio of the AVRi output to the
pulses at the binary outputs AVR up and AVR dn. Adjust the setpoint to the pulse
duration which is needed for the AVR to change the requested voltage from
minimum to maximum.
Group: Force value
Setpoint: Force value 1
This is one of the 16 setpoints reserved for using as alternative setpoints for the
force value functions. The alternative setpoint is to be assigned to a particular
force value function and renamed in GenConfig.
See also the input Force value 1.
NOTE:
It is not obligatory to use one of these reserved setpoints for a force value
function. It is possible to use also any other setpoint or value with matching
dimension and decimal resolution.
NOTE:
There isn't any relation between the default names of the force value function
blocks, associated binary inputs and the default names of the reserved setpoints.
In other words, the setpoint with default name Force value 3 is not related to the
Force value 3 function block.
Setpoint: Force value 2
This is one of the 16 setpoints reserved for using as alternative setpoints for the
force value functions. The alternative setpoint is to be assigned to a particular
force value function and renamed in GenConfig.
NOTE:
