IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
ï‚· If the input is active when the engine is expected to be stopped, then the
Stop fail alarm is issued and start is blocked.
ï‚· If the input becomes active while cranking, the engine is considered as
started and the start-up procedure continues to the next phase (idle).
NOTE:
Learn more in the separate chapter Starting sequence.
Binary input: RunIndication 3
This input is one of three inputs used for indication, that the engine is running, and
has following functions:
ï‚· If the input is active when the engine is expected to be stopped, then the
Stop fail alarm is issued and start is blocked.
ï‚· If the input becomes active while cranking, the engine is considered as
started and the start-up procedure continues to the next phase (idle).
NOTE:
Learn more in the separate chapter Starting sequence.
Binary input: IssueActCallC1
This input forces the controller to issue an active call/e-mail/SMS via the channel
#1. Type of the channel is to be adjusted by the setpoint AcallCH1-Type.
This input can be used to inform a remote user about a specific non-alarm
situation, e.g. mains failure and/or mains return:
1. Select a binary signal in the controller, which indicates, that the particular
situation occured, about which you want to be informed remotely. There
are many predefined binary informations provided directly by the
controller or use PLC functions to create the desired binary signal.
2. Configure an universal protection block to the binary signal mentioned
above and select protection type AL indication.
3. Configure the binary signal mentioned above onto the logical binary input
IssueActCallC1.
Binary input: IssueActCallC2
This input forces the controller to issue an active call/e-mail/SMS via the channel
#2. Type of the channel is to be adjusted by the setpoint AcallCH2-Type.
This input can be used to inform a remote user about a specific non-alarm
situation, e.g. mains failure and/or mains return:
1. Select a binary signal in the controller, which indicates, that the particular
situation occured, about which you want to be informed remotely. There
are many predefined binary informations provided directly by the
controller or use PLC functions to create the desired binary signal.
