Binary input: ForceValueIn16
This input activates the Force value #16 block. If the input is active, the value of
the setpoint, to which the Force value #16 block is configured, will be overriden by
value of the alternative setpoint assigned to the Force value #16 block.
NOTE:
If there are more than one force value blocks configured onto one setpoint then
the highest priority has the block with the lowest index (i.e. the first active block
according to the list displayed in GenConfig in the Force value window at the
related setpoint).
NOTE:
Watch a training video about force value function here:
http://www.comap.cz/support/training/training-videos/.
NOTE:
See an example in the description of the binary input Force value 1.
Binary input: Force block 1
This is one of three binary inputs used for user-defined blocking of protections. If
the input is active, all the protections that have Protection block type configured as
Force block 1 block type are blocked (i.e. temporarily disabled).
Binary input: Force block 2
This is one of three binary inputs used for user-defined blocking of protections. If
the input is active, all the protections that have Protection block type configured as
Force block 2 block type are blocked (i.e. temporarily disabled).
Binary input: Force block 3
This is one of three binary inputs used for user-defined blocking of protections. If
the input is active, all the protections that have Protection block type configured as
Force block 3 block type are blocked (i.e. temporarily disabled).
Binary input: Lang sel int A
This is one of three binary inputs Lang sel int A, Lang sel int B, Lang sel int C,
used for selecting language of the built-in IG-NT terminal (display). As the IS-NT
does not have built-in terminal, this input is assigned to the terminal (display) #1,
which is supposed to be directly attached to the controller or mounted close to it.
NOTE:
Using these inputs for language selection is an option only. If the inputs are not
configured, the language can be selected using the menus on the terminal.
