then opens again. This output is activated even if the selected breaker is actually
not tripped because of the input Sd override is active.
NOTE:
See also the output VectorShiftTrp.
Binary output: Common Wrn
The output is closed while there is at least one alarm of the Warning type present
in the alarm list. The alarm can be in any state, i.e. active unconfirmed, active
confirmed or inactive unconfirmed. See the chapter Alarm management for more
information.
Binary output: Common Sd
The output is closed while there is at least one alarm of the Shutdown type
present in the alarm list. The alarm can be in any state, i.e. active unconfirmed,
active confirmed or inactive unconfirmed. See the chapter Alarm management for
more information.
Binary output: Common SdOvr
Common output that closes with 2s delay if any Shutdown override-type protection
becomes active. If it is already active and another protection of that type becomes
active, the output is deactivated for 2 seconds and then reactivated again to
inform on this new alarm.
Binary output: Common Stp
The output is closed while there is at least one alarm of the Slow stop type
present in the alarm list. The alarm can be in any state, i.e. active unconfirmed,
active confirmed or inactive unconfirmed. See the chapter Alarm management for
more information.
Binary output: Common Fls
The output is closed while there is at least one alarm of the Sensor fail type
present in the alarm list. The alarm can be in any state, i.e. active unconfirmed,
active confirmed or inactive unconfirmed.See the chapter Alarm management for
more information.
Binary output: Common LoP
