ComAp IS-NTC-BB Reference Guide

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
343
It is possible to lock UserButton commands in configuration to specific user level.
Buttons 1-8 and 9-16 are locked separately.
ON
Pressing the button changes the state of log. binary output User
Button X to closed. When the output is closed and the button is
pressed state is not changed.
OFF
Pressing the button changes the state of log. binary output User
Button X to opened. When the output is opened and the button is
pressed state is not changed.
ON/OFF
Pressing the button changes the state of log. binary output User
Button X to opened or closed depending on previous state (it is
changed to the opposite state).
PULSE
ON
Pressing the button issues log. binary output User Button X to
close for one second.
NOTE:
Repeated pressing of button during the closed period (one
second) causes issuing another puls of length of one second to
be generated from the moment of button pushing.
Binary output: User Button 3
Related FW
3.0
Description
This output can be specified for example on buttons on IV-5/8 or in SCADA
diagram in InteliMonitor. Its state depends on function assigned to the related
button.
It is possible to lock UserButton commands in configuration to specific user level.
Buttons 1-8 and 9-16 are locked separately.
ON
Pressing the button changes the state of log. binary output User
Button X to closed. When the output is closed and the button is
pressed state is not changed.
OFF
Pressing the button changes the state of log. binary output User
Button X to opened. When the output is opened and the button is
pressed state is not changed.
ON/OFF
Pressing the button changes the state of log. binary output User
Button X to opened or closed depending on previous state (it is
changed to the opposite state).
PULSE
ON
Pressing the button issues log. binary output User Button X to
close for one second.
NOTE:
Repeated pressing of button during the closed period (one
second) causes issuing another puls of length of one second to
be generated from the moment of button pushing.
Binary output: User Button 4
Related FW
3.0
Description
This output can be specified for example on buttons on IV-5/8 or in SCADA
