INSTALLATION GUIDE FOR mBDA OD SERIES
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 11
102
71
338
210
Figure 2: Front, Side and Bottom Views of the dual-band combiner Enclosure
Note: Only when the dual-band mBDA is required, and the combiner is ordered separately.
End of Section
