COMBA mBDA OD Series - WEB GUI; WEB GUI CONNECTION

INSTALLATION GUIDE FOR mBDA OD SERIES
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 32
5 WEB GUI
mBDA can be monitored and controlled by WEB GUI, follow below contents to achieve system parameter
setting and commissioning.
5.1 WEB GUI CONNECTION
Step 1: Connect OMT port to PC RJ45 port with the supplied RJ45 cable to set up a physical connection.
Step 2: Open browser (browser IE7.0, IE8.0, Chrome or Firefox, suggest display resolution is 1024×768),
input Web GUI IP address: 192.168.8.101, click [Enter].
NOTE: DHCP and DNS are also available to login Web GUI. The domain name is: www.combaomt.com.
Figure 24: Input IP Address
Figure 25: Input Domain Name
Step 3: Input User Name: admin; Password (default password: admin). Click [Log in].
Figure 26: Input User Name and Password
5.2 WEB GUI INTRODUCTION
After log in, the Web GUI main screen will appear.
