Mounting Rack Bolt
Figure 12: Install Mounting Rack Bolt
4-M6×12,Hex Socket
with Washer Bolt
Mounting Rack2
The second mBDA
Figure 13: Install Mounting Rack2
4-M6×12,Hex Socket
with Washer Bolt
Wall
The Fist mBDA
The Second mBDA
Figure 14: Hand up and Secure the second mBDA
