COMBAT CUHA - Section 2. Technical Data; Table 2.1 General Technical Data - All Models

Page 11
UNIT HEATER
Fig 2.7 Dimensions etc. CUHD 60 to 300
Burner Compartment
25mm Mez. Flange Duct Connection Spigot
Electrical Supply via Cable Gland
Honeywell Combina- tion Fan/ Limit Stat.
WARNING ! Isolate Before Removing Cover
Combustion Air Slots
Access to Second Limit Thermostat
Lighting Instructions
Data Plate
Pilot viewing via cut out
Gas Connection
Electrical Connec- tions for Gas Valve and Interrupter Relay
Rear Honeywell Combination Fan/ Limit Stat.
Model
Ref.
60 80 100 120 140 160 180 200 240 280 300
A Width
mm
(ins)
519
(20½)
519
(20½)
589
(23)
589
(23)
729
(28½)
729
(28½)
869
(34)
869
(34)
1009
(39¾)
1219
(48)
1219
(48)
B Support
Spacing
mm
(ins)
479
(18)
479
(18)
549
(21¾)
549
(21¾)
689
(27¼)
689
(27¼)
829
(32¾)
829
(32¾)
969
(38¼)
1179
(46½)
1179
(46½)
C Flue Dia.
mm
(ins)
178
(7)
178
(7)
178
(7)
178
(7)
178
(7)
178
(7)
229
(9)
229
(9)
254
(10)
254
(10)
254
(10)
D Duct
Spigot Width
mm
(ins)
438
(17¼)
438
(17¼)
508
(20)
508
(20)
648
(25½)
648
(25½)
788
(31)
788
(31)
928
(36½)
1137
(44¾)
1137
(44¾)
Weight kg 82 82 92 99 104 114 124 134 154 180 180
