COMBAT CUHA - Table 2.2 Technical Data Manual Ignition Range

Page 12
UNIT HEATER
Fig 2.7 Dimensions etc. CUHD 340 to 380
Access to Second Limit Thermostat
Data Plate
Lighting Instructions
Honeywell Combina- tion Fan/ Limit Stat.
Combustion Air Slots
WARNING ! Isolate Before Removing Cover
Rear Honeywell Combination Fan/Limit Stat.
Burner Compartment
25mm Mez. Flange Duct Connection Spigot
Gas Connection
Pilot viewing via cut out
Electrical Connections for Gas Valve and interrupter relay
Electrical Supply via Cable Gland
Model
Ref.
340 380
A Width
mm
(ins)
1359
(53½)
1499
(59)
B Support
Spacing
mm
(ins)
1319
(52)
1459
(59)
C Flue Dia.
mm
(ins)
305
(12)
305
(12)
D Duct
Spigot Width
mm
(ins)
1277
(50¼)
1417
(55¾)
Weight kg 190 190
Flue Connections Assembled on Site
