DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 3-149
Default Settings
Note 1: Range for “Length” for all items is 1-4.
Note 2: Range for all “Leading” items is any available, non-conflicting directory number.
Flexible Numbering Plan – CO Line Group Defaults
Length Leading Length Leading Length Leading Length Leading Length Leading
1 1 2 2 3 3 4 4 5 5
Resulting
Code
1 9 3 80 Null Null Null Null Null Null 9,800-806
Flexible Numbering Plan – Directory Number Defaults
Leading Digit(s)
Length
1 2 3 4 5 6 7 8
Resulting
Code
Operator Code 1 0 na 0
Account Code 2 79 na 79
Extension 3 1 Null Null Null Null Null Null Null 100-199
Ext. Page Group 3 40 Null Null na 400-408
Hunt/UCD Groups 3 41 42 43 na 410-433
Pickup Groups 3 44 Null Null na 440-447
Individual Speed Dial 3 47 48 49 na 470-499
CO Line DIR No. 3 74 75 Null na 740-755
Music Source 3 771 772 Null na 771,772
Loud Bell Control 3 779 Null Null na 779
External Pager 3 777 Null Null na 777
Virtual Number 3 70 71 72 na 700-729
Meet Me Conference 3 39 Null Null na 390-397
Programming Abstract
• Program the Directory Number Length for each of the system resources.
• Program the digits for the selected resource. Special consideration should be taken when applying digits to
resources. Any resource may be assigned all specific digits or only the first digit(s) based on the Length total
for each resource and those Leading digits assigned.
Programming via the DET (Digital Extension Terminal)
Note: [back], [next], [show], [chg], [bksp], and [save] are LCD interactive button operations. Use the
three buttons below the LCD display to actuate the associated operation.
• Enter Database Administration using the feature code !+* and then enter the DB Admin password
“++++++++.” (Note: This eight-character password can be changed.)
• Press [show ]. The DB Item Select screen displays.
• Input 08-09-01, then press [save]. This advances to Numbering Plan – CO Group programming.
• Press [show ] to enter into CO Group numbering plan programming.
Or…
