DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-18
+--------------------------------- DX80 PC-DBA --------------------------------+
¦ [Cnt] KSU Revision : K16UM0.F19 Date: 01/02/14 ¦
¦ Time: 20:43:58 ¦
¦ Diagnostics : ¦
¦ ¦
¦ BOARD TYPE RESULT ¦
¦ COMMON CTRL BOARD CPM BOARD PASSED ¦
¦ OPTION BOARD 8 VOICE MAIL BOARD CONNECT ¦
¦ MODEM BOARD MDM BOARD TESTING ¦
¦ Cabinet 1 ¦
¦ Cabinet 2 ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
+----------------------------------- R16UM0.F21 -------------------------------+
+--------------------------------- DX80 PC-DBA --------------------------------+
¦ [Cnt] KSU Revision : K16UM0.F19 Date: 01/02/14 ¦
¦ Time: 20:44:35 ¦
¦ Diagnostics - CPM BOARD : PASSED ¦
¦ ¦
¦ RS232-1 :PASSED ¦
¦ ¦
¦ ¦
¦ RS232-2 :PASSED ¦
¦ ¦
¦ ¦
¦ ROM CHECK : PASSED ¦
¦ ¦
¦ ¦
¦ RAM CHECK : PASSED ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
+----------------------------------- R16UM0.F21 -------------------------------+
Notes:
This is an overview screen of test results.
• At the time this report was taken the Modem Module (MDM) was in the
testing state.
• Notice that the PC-8 Module reports “CONNECT.” Since the PC-8 is its own
self-contained system that runs independently of the DX-80 processor,
“CONNECT” and “DISCONNECT” are the only conditions reported for this
module.
• Move the cursor to any board/Cabinet and press « to get details of that
board.
Note:
Detail of CPM Board
