DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-19
+--------------------------------- DX80 PC-DBA --------------------------------+
¦ [Cnt] KSU Revision : K16UM0.F19 Date: 01/02/14 ¦
¦ Time: 20:45:23 ¦
¦ Diagnostics - Cabinet 1 ¦
¦ ¦
¦ BOARD TYPE ¦
¦ BOARD 1 408 BOARD ¦
¦ BOARD 2 OPEN ¦
¦ BOARD 3 OPEN ¦
¦ BOARD 4 APM4 ¦
¦ BOARD 5 COM4 ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
+----------------------------------- R16UM0.F21 -------------------------------+
F1-Help F2-U-Save F3-RCV F4-SND F5-Cnt F6-Disc F7-Prn F8-Init F9-Mdm F10-RS232C
+--------------------------------- DX80 PC-DBA --------------------------------+
¦ [Cnt] KSU Revision : K16UM0.F19 Date: 01/02/14 ¦
¦ Time: 20:45:58 ¦
¦ Diagnostics - 408 BOARD : ¦
¦ ¦
¦ COL POS DIR# LOOP DISC ¦
¦ 1/01/1 740 PASSED PASSED ¦
¦ 1/01/2 741 BUSY IN ¦
¦ 1/01/3 742 BUSY OUT ¦
¦ 1/01/4 743 FAILED FAILED ¦
¦ ¦
¦ ¦
¦ EXT POS DIR# TYPE RESULT ¦
¦ 1/01/1 101 EXEC. DISPLAY PASSED ¦
¦ 1/01/2 102 EXEC. DISPLAY FAILED ¦
¦ 1/01/3 103 NO CONNECTION OPEN ¦
¦ 1/01/4 104 EXEC. DISPLAY OPEN ¦
¦ 1/01/5 105 NO CONNECTION OPEN ¦
¦ 1/01/6 106 NO CONNECTION OPEN ¦
¦ 1/01/7 107 NO CONNECTION OPEN ¦
¦ 1/01/8 108 NO CONNECTION OPEN ¦
¦ ¦
+----------------------------------- R16UM0.F21 -------------------------------+
Note:
• Cabinet 1 selected.
• Move the cursor to any
board and press « to
get details of that board.
CO Lines:
• Ports
1/01/1~1/01/4
• Directory
numbers
740~743
Extensions
• Ports
1/01/1~1/01/8
• Directory
numbers
101~108
• Passed = Loop
Current
detected.
• Busy
• Failed = No
Loop Current
• Passed = Loop OK
• In = Incoming call
• Out = Outgoing call
• Failed = Loop Fail
• Digital Executive Telephone
• No Connection = no device
attached.
• Passed = operation OK.
• Failed = data communications
error to device.
• Open = either no connection
ever registered or previous
registered device is no longer
connected.
408 Board Selected
