DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-20
+--------------------------------- DX80 PC-DBA --------------------------------+
¦ [Cnt] KSU Revision : K16UM0.F19 Date: 01/02/14 ¦
¦ Time: 20:46:53 ¦
¦ Diagnostics - COM4 BOARD : ¦
¦ ¦
¦ COL POS DIR# LOOP DISC ¦
¦ 1/05/1 744 OPEN OPEN ¦
¦ 1/05/2 745 OPEN OPEN ¦
¦ 1/05/3 746 OPEN OPEN ¦
¦ 1/05/4 747 OPEN OPEN ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
+----------------------------------- R16UM0.F21 -------------------------------+
+--------------------------+
¦ Exit This Feature ? (Y/N)¦
+--------------------------+
+------------------+
¦ Self Test ¦
+------------------¦
¦ System ¦
¦ Board ¦
¦ Port ¦
+------------------+
+--------------------+
¦ CPM BOARD ¦
¦ 8 VOICE MAIL BOARD ¦
¦ MDM BOARD ¦
¦ CABINET 1 ¦
¦ CABINET 2 ¦
+--------------------+
COM4 / Board 5 Selected
• Passed = Loop OK
• In = Incoming call
• Out = Outgoing call
• Failed = Loop Fail
• Open = Not Equipped
Press ° then “Y”
to exit this screen
Invoke another test by
selecting from the list.
