DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-21
+--------------------+
¦ C.CTRL BOARD ¦
+--------------------¦
¦ RS232-1 ¦
¦ RS232-2 ¦
¦ ROM ¦
¦ RAM ¦
+--------------------+
+--------------------+
¦ Self Test ¦
+--------------------¦
¦ Wait For Result ¦
¦ Do Not Wait ¦
+--------------------+
+----------------------------------------+
¦ Port Test ¦
+----------------------------------------¦
¦ BOARD : C.CTRL ¦
¦ ¦
¦ PORT RESULT ¦
¦ ROM PASSED ¦
¦ ¦
+----------------------------------------+
+--------------------------+
¦ Exit This Feature ? (Y/N)¦
+--------------------------+
Status
The Status function can be invoked to view specific DX-80 system resource status. Move the cursor to the
system resource to view and press «.
+--------------------+
¦ Status ¦
+--------------------¦
¦ CPM BOARD ¦
¦ 8 VOICE MAIL BOARD ¦
¦ MDM BOARD ¦
¦ CABINET 1 ¦
¦ CABINET 2 ¦
+--------------------+
Port of CPM Board selected
Do Not Wait selected.
“ROM” (Read Only
Memory, hard-coded
system memory) test
passed.
Press ° then “Y”
to exit this screen
