Comdial DX-80 - Page 338

DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-22
+--------------------------------- DX80 PC-DBA --------------------------------+
¦ [Cnt] KSU Revision : K16UM0.F19 Date: 01/02/14 ¦
¦ Time: 20:52:26 ¦
¦ Status - CPM BOARD : ¦
¦ ¦
¦ RS232-1 :BUSY ¦
¦ ¦
¦ ¦
¦ RS232-2 :IDLE ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
+----------------------------------- R16UM0.F21 -------------------------------+
+--------------------------------- DX80 PC-DBA --------------------------------+
¦ [Cnt] KSU Revision : K16UM0.F19 Date: 01/02/14 ¦
¦ Time: 20:52:57 ¦
¦ Status - OPTION BOARD : ¦
¦ ¦
¦ ¦
¦ ¦
¦ 8 VOICE MAIL BOARD : CONNECT ¦
¦ Voice Mail 1 : IDLE ¦
¦ Voice Mail 2 : IDLE ¦
¦ Voice Mail 3 : IDLE ¦
¦ Voice Mail 4 : IDLE ¦
¦ Voice Mail 5 : IDLE ¦
¦ Voice Mail 6 : IDLE ¦
¦ Voice Mail 7 : IDLE ¦
¦ Voice Mail 8 : IDLE ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
¦ ¦
+----------------------------------- R16UM0.F21 -------------------------------+
Select the appropriate
system resource/device
and press «.
• Idle = Ready for a call
• Busy = Port in use
Press ° then “Y” to
exit this screen and
select another.
