Comelit 6801W - Programming Range Settings; Setting Address Range and Deleting

17
1) 2) 3) 4)
Range
minimum
address
S1
set code,
addressing table
S2 DIP
1 2 3 4 5 6
0 0 0 0 1 0
S2
1
x4
x10
S2
Range
maximum
address
2
Enable range
2 sec.
1
Disable range
2 sec.
2
Deleting the
range
DIP OFF
DIP ON
S1
S2 DIP
1 2 3 4 5 6
1 1 1 1 1 0
S2
2 sec.
f Carry out steps 1 to 4
Programming range
Take note of the S2, S1 setting and restore it when programming is complete
