Comelit 6801W - LED;Actuator Function Programming; Input Programming for LED, Alarm, Lock-Release, Actuator

18
f Carry out steps 1 to 4
LED/alarm/lock-release/actuator programming
Take note of the S2, S1 setting and restore on completion of programming
1) 2) 3) 4)
Input IN 1- IN 2
LED (default)*
S2 DIP
1 2 3 4 5 6
0 0 0 1 1 0
S2
1
x4
x10
S2
Input CFP2 - IN 1
ALARM*
2
Input CFP2 - IN 1
LOCK-RELEASE*
S2 DIP
1 2 3 4 5 6
0 0 1 0 1 0
S2
1
Input CFP2 - IN 1
CODED ACTUATOR*
S1
set code,
addressing table
2
Input CFP2 - IN 1
GENERIC ACTUATOR*
DIP OFF
DIP ON
S1
2
* See "Connections".
