Comelit 8461V - External Unit Settings

10
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
ON
The lock-
release relay
and the
second relay
are controlled
by 2 separate
buttons (e.g.
lock-release
button and
actuator
button)
ON
lock-release
activation time:
8 sec.
ON
relay activation
time: 8 sec.
ON
reset wait time:
1 sec.
ON
Call
transmission:
triple
ON
confirmation
tones (call,
lock-release,
relay, audio
enabled):
disabled
ON
Camera
lighting LED:
disabled
ON
LED lighting
of nameholder
front panels:
OFF
OFF
The lock-
release relay
and the
second relay
are controlled
by a single
button (e.g.
lock-release
button)
OFF
lock-release
activation time:
2 sec.
OFF
relay activation
time: 2 sec.
OFF
reset wait time:
10 sec.
OFF
Call
transmission:
single
OFF
confirmation
tones (call,
lock-release,
relay, audio
enabled):
enabled
OFF
Camera
lighting LED:
enabled
OFF
LED lighting
of nameholder
front panels:
ON
External unit settings
f Set the DIP-switches of S1 corresponding to the function that you want to programme as shown in the table below
