Comelit 8461V - Programming Buttons for Other Functions

23
Programming buttons for other functions
Legend
Lock- release
AI Self-ignition
K Guardian doorentry phone call
D Doctor
PROG Programmed functions
Example:
on a monitor with user code 5, P1 programming = self-ignition, P2= Doctor.
1. Set S2 DIP switch 6 to the combination 01.
» the privacy LED flashes.
S2 DIP
1 2 3 4 5 6
0 0 0 0 0 1
S2
2. Refer to the table on page 23 and select a combination in which the desired/necessary functions are listed for the keys
you wish to program.
E.g. 1: for P1= self-ignition, P2= Doctor, set S2 DIP switches 1-2-3-4 to the combination 0110 (P1=AI,P2=D).
3. Press and release the keys to which you wish to assign the functions
» the lock-release LED lights up.
» une tonalité de confirmation retentit.
4. To exit programming mode, set S2 DIP switches 5-6 to the combination 00
» the privacy LED switches o.
5. When programming is complete, set S2 DIP switches 1-2-3-4 to the combination 1111.
DIP S2 Art. 6721W(/BM) + Art. 6734
DIP 1 DIP 2 DIP 3 DIP 4 P1 P2
P3 P4 P5
0 0 0 0 AI D
1 0 0 0 AI D
0 1 0 0 AI
1 1 0 0 K
0 0 1 0
1 0 1 0
0 1 1 0 AI D K
1 1 1 0 AI
0 0 0 1 D AI
1 0 0 1 K AI
0 1 0 1 K
1 1 0 1 K
0 0 1 1 AI D
1 0 1 1
0 1 1 1
1 1 1 1 PROG
