Commell MS-C75 - Connector Reference

MS-C75 User’s Manual
-12-
2.3 <Connector Reference>
2.3.1 <Internal Connectors>
Connector
Function
Remark
CPU
Socket rPGA988B for PGA988 CPU
SO-DIMM 1/2
204 -pin DDR3 SO-DIMM socket
SATA 1/2
7-pin Serial ATAIII connector
SATA 3/4/5/6
7-pin Serial ATAII connector
CN_12V
4-pin +12v additional power supply connector
ATX
24-pin power input connector
CN_AUDIO
5 x 2-pin audio connector
CD_IN
4-pin CD-ROM audio input connector
CN_DIO
6 x 2-pin digital I/O connector
CN_USB 1/2/5
5 x 2-pin USB connector
CPUFAN
4-pin CPU cooler fan connector
SYSFAN
4-pin system cooler fan connector
CN_LVDS
20 x 2-pin LVDS connector
CN_INV
5-pin LCD inverter connector
CN_IR
5-pin IrDA connector
CN_COM 4/5/6
9-pin RS232
CN_LPC
5 x 2-pin LPC connector
JFRNT
14-pin front panel switch/indicator connector
PCIE_16X
164-pin x16 PCIE slot
PCIE_4X
64-pin x4 PCIE slot
Mini-PCIE1
2 x 52-pin Mini-PCIE socket
PCI
120-pin PCI slot
MiniPCI
124-pin MiniPCI slot
JAT
Power mode select
JSPD 1/2
LAN Speed LED connector
JACT 1/2
LAN Activity LED connector
CN_LPT
13 x 2 printer connector
2.3.2 <External Connectors>
Connector
Function
Remark
USB_RJ45 1/2
2 x USB3.0 and 1 x RJ45 LAN connector
COM1 + CRT
COM1 Connect DB15 and analog VGA connector
COM 2/3
Serial port connector
PS/2
PS/2 keyboard and mouse connector
AUDIO
Audio connector
SPDIF
SPDIF digital audio output connector
