MS-C75 User’s Manual
-7-
1.2 <Product Specification>
3
rd
Generation Intel® Core™ i7, Core™ i5, Core™ i3 Mobile Processor
Package type: rPGA988B
2 x DDRIII SO-DIMM 1066/1333/1600 MHz up to 16GB
Intel QM77 Express chipset
Chipset integrated RTC with onboard lithium battery
Generates a system reset with internal timer for 1min/s ~255min/s
Supports ACPI 3.0 compliant,
4 x serial ATAII interface with 300MB/s transfer rate
2 x serial ATAIII interface with 600MB/s transfer rate
Onboard DSUB15 connector for VGA interface
Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V
supply
Onboard DVI 20-pin connector
1 x Intel 82579LM Gigabit LAN
1 x Intel 82574L Gigabit LAN
Onboard programmable 8-bit Digital I/O interface
1 x PCIe x16/x4 slot, 1 x PCIe mini card socket, 2 x PCI, 1 x Mini PCI
(Optional support mSATA(SATAII) for Mini_Card1,but SATA6 will be
disable)
3 x RS232,1 x SMBUS, 1 x GPIO, 6 x USB2.0 ports, 1 x IrDA, 1 x DVI ,
1 x LVDS, 4 x Serial ATAII,2 x Serial ATAIII, 1 x Front panel Audio
and 1 x CDIN
1 x PS/2, 2 x LAN ports, 1 x VGA port, 4 x USB3.0 ports,
1 x RS232/422/485, 2 x RS232, 1 x SPDIF and 1 x 2 Channel Audio
Standard 24-pin ATX power supply (20-pin is compatible)
and P4 4-pin 12V
Operating within 0~60 centigrade
Storage within –20~85 centigrade
Intel PGA988B+ QM77 Onboard VGA, LVDS, DVI, LAN, USB2.0,
USB3.0, HD Audio, SATAII, SATAIII, SMBUS, LPC, SIM, GPIO,
PCIE x16, PCI and Mini PCI, PCI Express mini card
Intel PGA988B+ QM77 Onboard VGA, LVDS, DVI, LAN, USB2.0,
USB3.0, HD Audio, SATAII, SATAIII, SMBUS, LPC, SIM, GPIO,
PCIE x16, PCI and Mini PCI, mSATA
All product specifications are subject to change without notice.
For further product information please visit the website at TUhttp://www.commell.com.twUT
