MS-C75 User’s Manual
-39-
Appendix A <I/O Port Pin Assignment>
A.1 <Serial ATA Port>
Connector: SATA1/2/3/4/5/6
Type: 7-pin wafer connector
1
2
3
4
5
6
7
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXN1
RSATA_RXP1
GND
A.2 <IrDA Port>
Connector: CN_IR
Type: 5-pin header for SIR Ports
A.3 <VGA Port>
Connector: CRT
Type: 15-pin D-sub female connector on bracket
Pin
Description
Pin
Description
Pin
Description
1
RED
6
Ground
11
N/C
2
GREEN
7
Ground
12
DDCDA
3
BLUE
8
Ground
13
HSYNC
4
N/C
9
N/C
14
VSYNC
5
Ground
10
Ground
15
DDCCLK
A.4 <LAN Port>
Connector: RJ45
Type: RJ45 connector with LED on bracket
Pin
Description
1
VCC
2
N/C
3
IRRX
4
Ground
5
IRTX
Pin
1
2
3
4
5
6
7
8
Description
MI0+
MI0-
MI1+
MI2+
MI2-
MI1-
MI3+
MI3-
1
6
10
1
2
3
4
5
11
12
13
14
15
5
7 1
8 1
