MS-C75 User’s Manual
-25-
CN_USB2/1/5
2.10 <USB Interface>
MS-C75 integrates four USB3.0 ports and six USB2.0 ports.
The specifications of USB3.0 are listed below:
Interface
USB3.0
Controller
Intel®QM77
Transfer Rate
Up to 5Gb/s
Voltage
5V
The specifications of USB2.0 are listed below:
Interface
USB2.0
Controller
Intel®QM77
Transfer Rate
Up to 480Mb/s
Voltage
5V
1 2
9 10
USB_RJ45_1
USB_RJ45_2
