Connector: CN_AUDIO
Type: 10-pin (2 x 5) header (pitch = 2.54mm)
Pin
Description
Pin
Description
1
MIC_L
2
Ground
3
MIC_R
4
N/C
5
Speaker_R
6
MIC Detect
7
SENSE
8
N/C
9
Speaker_L
10
Speaker Detect
Connector: CDIN
Type: 4-pin header (pitch = 2.54mm)
Pin
Description
1
CD – Left
2
Ground
3
Ground
4
CD – Right
1
4
1
2
10
9
