Compaq dc5800 - Microtower PC User Manual

Example 1—Using the “Advanced Settings” page to allow Windows logon from
Credential Manager
1. Select Start > All Programs > HP ProtectTools Security Manager.
2. In the left pane, click Credential Manager, and then click Settings.
3. In the right pane, click the General tab.
4. Under Select the way users log on to Windows (requires restart), select the Use Credential
Manager with classic logon prompt check box.
5. Click Apply, and then click OK.
6. Restart the computer.
NOTE: Selecting the Use Credential Manager with classic logon prompt check box allows you to
lock your computer. See “
Locking the computer on page 15.”
Example 2—Using the “Advanced Settings” page to require user verification before
Single Sign On
1. Select Start > All Programs > HP ProtectTools Security Manager.
2. In the left pane, click Credential Manager, and then click Settings.
3. In the right pane, click the Single Sign On tab.
4. Under When registered logon dialog or Web page is visited, select the Authenticate user
before submitting credentials check box.
5. Click Apply, and then click OK.
6. Restart the computer.
Advanced tasks (administrator only) 23

Compaq dc5800 - Microtower PC Specifications

General

Processor	Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Celeron
Memory	Up to 8 GB DDR2 SDRAM
Graphics	Integrated Intel Graphics Media Accelerator 3100
Optical Drive	DVD-ROM, DVD+/-RW
Form Factor	Microtower
Expansion Slots	1 PCI, 2 PCIe x1, 1 PCIe x16
Audio	Integrated High Definition Audio
Network	Integrated Gigabit Ethernet
Ports	VGA, Serial, Parallel, PS/2, Audio in/out
Operating System	Windows Vista Business, Windows XP Professional
Power Supply	300W
USB Ports	8 USB 2.0 (2 front, 6 rear)
