When returning the drive cage from its elevated position to its resting
position, lower the cage slowly and keep fingers clear of its travel path.
>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<
>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>> CAUTION <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<
When returning the drive cage to its resting position, ensure that none of
the cables are pinched between the drive cage and the base pan.
>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<
5. Connect the power switch (Figure 5-11).
6. Release the metal drive cage release (Figure 5-13) and lower the drive
cage to its seated position.
7. Install the unit cover assembly (Figure 5-7).
>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>> CAUTION <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<
Verify that the power supply voltage select switch is set to the proper
voltage before applying power to the system.
>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<
Chapter 5.6 Power Switch
To remove and replace the power switch, complete the following steps:
1. Complete the steps in Section 5.3 to prepare the computer for
disassembly.
2. Complete the steps in Section 5.4 to remove the unit cover assembly to
gain access to the power switch.
3. Remove the switch cap; it easily slides off the front of the switch
(Figure 5-19).
