4-6 ENGINE CONTROLS
1- IGNITION SWITCH. Set this switch in START position for
start engine. Placein OFF position for Stop Engine.
2- SPEED CONTROL
In RUN/IDLE position, engine runs at idle speed at
no load, and change automatically to speed
operation ( 3700 RPM ) just when begin to weld or connect
a load in auxiliary power.
In RUN position, the engine runs at 3700 RPM, is
recommended use this position when use auxiliary power
and constant voltage option either.
Always the Unit is not Use Place the Switch in the OFF
position, to preven discharging the battery.
4- CHOKE. Choke control is provided for varying the fuel-air
mixture to the engine. Set ignition switch in Start position.
Pull totally choke BEFORE START engine. Press the
Push Button To Activate the Start Engine; Left Press when
4-5 AMPERAGE / VOLTAGE FINE CONTROL
1.- FINE CONTROL (AMPERAGE/ VOLTAGE)
Use control to set weld amperage or voltage within the range
selected by the coarse range selector.
The scale is a percentage of the range selected non an actual
amperage or voltage value.
Control may be adjusted while welding.
NOTE: SET AT 7-10 FOR POWER WHILE WELDING
SET AT 10 FOR MAX. GENERATOR POWER
