Comparc BRONCO 255K XD - SECTION 3 INSTALLATION; Location Selection and Unit Moving; Unit Dimensions and Weight; Exhaust Pipe Installation Guide

PM1323
FRONT
RIGTH
TOP
REAR
LEFT
SECTION 3 INSTALLATION
CAUTION
1
25°
25°
25°
25°
C 1111
B 19.6
31.5
A
43.75
Sin manubrio
A
C
43.3
44
Allocate and install the exhaust in the
wished direction. If the machine is install
on a truck or trailer, do not install it in the
trafic flow direction
3-3. EXHAUST PIPE
12.7mm (1/2")
/
3-1 SELECTING A LOCATION & MOVING WELDING SOURCE.
READ SAFETY BLOCKS at beginning of
manual before proceeding.
1.- Keep free space 457mm (18")
around the unit for a good air
flow.
2.- Lifting eye. Use only for lift the
unit.
3.- Exhaust pipe
1.- Trailer.
Do not exceed tilt angles or
engine could be damaged or
unit could tip.
Do not move or operate unit
where it could tip.
INCHES OBSERVATIONS
W / Lifting eye
3-2 OVERALL DIMENSIONS
TOOLS NEEDED
1
W / Exhaust pipe
A
I
R
A
I
R
A
I
R
A
I
R
A
I
R
A
I
R
3
2
4
WEIGHT:
NET: 586.43 Lb
SHIP:606.27 Lb
