DMD1050 Satellite Modem Board Rear Panel Interface
Figure 4-3. DMD1050 Top View
SMA OPT (F)
TX L-BAND
SMA OPT (F)
RX L-BAND
J9
Compact
Flash Card
J7
INPUT
POWER
2
J11
RJ45
Ethernet
Data
J10
RJ45
M&C
J8
SMA
FEMALE
MN-DMD1050 4–3
Revision 9
